1  Applicable Fiber

       Single mode and Multi mode silica based optical fiber

       Cladding diameter    100 to125µm

       Coating diameter     0.1 to 1.0mm

       Fiber cleaved length: 16mm(standard)

2 Specifications:

       · Dimension:   172mm(length) x186mm (width)

        x220mm (height)

       · Weight:      Only 3.7 Kg

       · Screen:             5.0 inch LCD colour Monitor

                             Display double light route picture

       · Environment:        Temperature:     -10～50℃

                             Storage:         -40～60℃

                             Humidity:       <95%RH (without dew)

                             Storage humidity:  no dew

       · Average fusion loss:   0.01dB (MMF), 0.02dB(SMF),

         0.04dB(NZDSF)

       · Average fusion time:   10sec. (Standard)

       · Average heat time:    40sec. (Standard)

       · Fusion program:

        SM,MM,DS,NZDS,EDF,EXF(Changable)

       · Languages selectable:  Chinese, English

        · Work style:          Auto,Manual

       · Power supply:        Alternating Current:176～264V,

           50Hz +15%                     Direct current:10.5～15V

       · Storage of splice result: 4000(selectable)
